AP6348-O
2000 Ampere 48H x 28.875L x 30.75W Aluminum Shell Copper Bus Bars 13 Position Per Phase And Neutral
| Specifications | |
|---|---|
| Amperage Rating | Up to 2000 Ampere |
| Application | Termination Cabinet |
| Brand Name | Milbank |
| Color | ANSI 61 Gray |
| Conductor Material | Copper and Aluminum |
| Conductor Size | NEMA Spaced Mounting Holes |
| Wire Connection | NEMASpacedMountingHoles |
| Material | G90 Galvanized Steel |
| Finish | Powder Coat Finish |
| Insulation Material | Haysite |
| Jacket Material | Polypropylene |
| Knockouts | False |
| Length | 28.875 IN |
| Number of Conductors | 13 |
| Phase | 3 |
| Size | 28.875L x 30.75W x 48H |
| Standard | Non UL Listed |
| Temperature Rating | No Temperature Rating |
| Type | Line to Load Distribution |
| Voltage Rating | Up to 600 Volts Alternating Current |
| Height | 48.0 IN |
| Width | 30.75 IN |
Please consult serving utility for their requirements prior to ordering or installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must be installed by a licensed electrician and must comply with all national and local codes, laws and regulations. Milbank reserves the right to make changes in specifications and features shown without notice or obligation.
