S2718-FB-XL-C
34.669H x 15.538L x 15W Polyphase Enclosure 1 Position With Backboard Small Closing Plate Demand Reset Cover
| Specifications | |
|---|---|
| Application | Enclosure for Mounting Electrical Equipment |
| Brand Name | Milbank |
| Cable Entry | Knockouts |
| Color | ANSI 61 Gray |
| Construction | Welded |
| Cover Type | Hinge Cover |
| Depth | 15.538 |
| Door | 1 Door |
| Finish | Painted |
| Height | 34.689 IN |
| Hinge Type | Concealed Lift Off Hinges |
| Insulation | Wood Back Panel |
| Knockouts | True |
| Latch | Door Hardware Provision |
| Material | G90 Galvanized Steel with Powder Coat Finish |
| Mounting | Pad Mount or Wall Mount |
| NEMA Rating | Type 3R |
| Number Of Outlet | 0 |
| Size | 15.538L x 15W x 34.689H |
| Standard | Non UL Listed |
| Top | Plain Top |
| Type | Hinge Cover |
| Width | 15.0 IN |
| Length | 15.538 IN |
Please consult serving utility for their requirements prior to ordering or installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must be installed by a licensed electrician and must comply with all national and local codes, laws and regulations. Milbank reserves the right to make changes in specifications and features shown without notice or obligation.
