UQFB-100
Appears In:
Milbank 100 Ampere 2 Pole 240 Volt Bolt-on 10k Ampere Interrupting Capacity
| Specifications | |
|---|---|
| Actuator | Lever |
| Application | Metering Accessory |
| Auxiliary Contacts | No Auxiliary Contacts |
| Brand Name | Milbank |
| Connection | LugtoLug |
| Amperage Rating | 100 Ampere |
| Frequency Rating | 60 Hertz |
| Interrupt Rating | 10,000 Ampere Interrupting Capacity |
| Material | Non Metallic |
| Phase | 1 Phase |
| Number Of Poles | 2 |
| Operating Temperature | 40 Degrees Celsius |
| Special Features | BoltOn |
| Standard | UL Listed |
| Trip Type | Thermal Magnetic |
| Type | Current Interrupting Device |
| Voltage Rating | 240 Volts Alternating Current |
| Height | 7.438 IN |
| Length | 3.281 IN |
| Width | 3.0 IN |
Please consult serving utility for their requirements prior to ordering or installing, as specifications and approvals vary by utility and may require local electrical inspector approval. All installations must be installed by a licensed electrician and must comply with all national and local codes, laws and regulations. Milbank reserves the right to make changes in specifications and features shown without notice or obligation.
